Product Information

Author

GGDesk LLC

Release Date

May-9-2020

Last Update

Jun-5-2024

Current Version

25.0.0

Language

ENGLISH

OS

WINDOWS 64-BIT

Autodesk Revit

2025, 2024, 2023, 2022, 2021, 2020

Product Description

Important: Run Lookup has been redesigned. The lengths of 'Conduit with Fittings' and 'Cable Tray with Fittings' have proven to be inaccurate. Therefore, we have discontinued support for these families.



Run Lookup is a streamlined add-in for Autodesk Revit that simplifies the calculation of the total length for selected conduit or cable tray runs. By factoring in angle bends in its calculations, Run Lookup excels in scenarios where the length or angle of a conduit run may be constrained.



The add-in is compatible with the following systems:

  • Conduits without fittings
  • Bend (Elbows)
  • Cable trays without fittings
  • Horizontal Bend
  • Vertical Inside Bend
  • Vertical Outside Bend



Run Lookup determines the total run length in the following way:

  • For conduits/cable trays without fittings (family): Run Lookup utilizes the Revit Run Schedule to extract the length, inclusive of any fittings of the type 'ELBOW'.



If you require an add-in to streamline the use of the run schedule in Autodesk Revit, we recommend our Data Ctrl app. This solution is designed to simplify your workflow.



FREE
